您的位置:首页 > 配电箱/电气柜生产线 >基业箱自动生产设备-基业箱生产设备

发布时间:2019-12-03 15:02:24

基业箱自动生产设备-基业箱生产设备

基业箱自动生产设备-基业箱生产设备是潍坊炜桦新一代智能设备,可实现基业箱箱体自动生产!

基业箱自动生产设备

基业箱自动生产设备-基业箱生产设备主要参数:

总电机功率:29kw

电压参数:380V/415V,50Hz, 3相

电气控制:PLC

驱动电机:变频电机驱动

钢带厚度:0.5~1.5 mm (视型材而定)

钢带宽度:≤1000mm,(视型材而定)

轧辊材质:铬十二 淬火HRC58°-62°

液压油型号:46#液压油

材料规格: 1、Q235   2、不锈钢  3、镀锌钢板

折弯方式:在线自动折弯成型

生产速度:0-12 m/min

切断方式:液压切断

切断尺寸公差:≤ ±0.3mm(长≤3000mm)

切断模具材质:铬十二钼钒

气源:0.5m3/Min;压力为0.8MPa

   “炜桦冷弯”我公司生产的配电箱成型流水线。动力柜柜体生产设备,配电箱箱体自动折弯成型机、消防箱生产线,光纤箱生产线等可根据客户的不同生产、工艺需求,设备配置,集成生产所需的众多工艺—自动送料、冲孔、折弯、成型。后续可选配机械手焊接等等;

配电箱成型流水线设备,——“炜桦冷弯”我们更专业!

Main parameters of distribution box forming line: total motor power: 29kw voltage parameter: 380V < 415V, 50Hz, 3-phase electrical control: PLC drive motor: frequency conversion motor drive steel strip thickness: 0.51.5 mm (depending on profile) steel strip width: ≤ 1000mm, (depending on profile) Roller material: chromium 12 quenched HRC58 °- 62 °hydraulic oil model: 46 # hydraulic oil material specification: 1, Q2352, stainless steel 3, Galvanized steel sheet bending mode: on-line automatic bending forming production speed: 0 to 12 m/min cutting mode: hydraulic cutting dimensional tolerance: ≤ ±0.3mm (length ≤ 3000mm) cutting die material: chromium 12 molybdate vanadium Gas source: 0.5m3 Minmin; The pressure is 0.8MPa "Wei Hua cold bending" our company produces the distribution box forming assembly line. Power cabinet production equipment, distribution box automatic bending molding machine, fire box production line, optical fiber box production line, etc., according to the customer's different production, process requirements, equipment configuration, Integrate many processes needed for production-automatic feeding, punching, bending, forming. Follow-up optional manipulator welding and so on; distribution box forming assembly line equipment,-"Wei Hua cold bending" we are more professional!
